Stock:
Distributor: 116
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 48000 | ₹ 26.42000 | ₹ 12,68,160.00 |
| 36000 | ₹ 27.10000 | ₹ 9,75,600.00 |
| 24000 | ₹ 27.81000 | ₹ 6,67,440.00 |
| 12000 | ₹ 28.57000 | ₹ 3,42,840.00 |
| 6000 | ₹ 30.20000 | ₹ 1,81,200.00 |
Stock:
Distributor: 108
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 3000 | ₹ 33.55000 | ₹ 1,00,650.00 |
| 6000 | ₹ 33.55000 | ₹ 2,01,300.00 |
| 12000 | ₹ 30.35000 | ₹ 3,64,200.00 |
| 18000 | ₹ 28.93000 | ₹ 5,20,740.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | SFV-R | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Flat Flexible Cable Style | FFC, FPC | |
| Attachment Mounting Style | Surface Mount, Right Angle | |
| Pin Interface Style | Contacts, Bottom | |
| Switch Position Options | 31 | |
| Component Spacing Distance | 0.020" (0.50mm) | |
| Circuit End Method | Solder | |
| Flat Flexible Cable Depth | - | |
| PCB Clearance Height | 0.071" (1.80mm) | |
| Retention Lock Mechanism | - | |
| Wire Termination Style | Tapered | |
| Pin Alloy Composition | Phosphor Bronze | |
| Pin Surface Treatment | Gold | |
| Casing Build Material | Liquid Crystal Polymer (LCP), Glass Filled, Halogen Free | |
| Activator Construction Material | Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free | |
| Key Product Highlights | - | |
| Max Voltage Specification | 50V | |
| Ambient Temp Range | -55°C ~ 105°C | |
| Fire Resistance Classification | UL94 V-0 |
Description
Made from Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free material to ensure durability. Designed with a cable end configuration known as Tapered. Showcases connector/contact type specified as Contacts, Bottom. Includes contact finish plated at Gold to improve conductivity. Constructed from the contact material known as Phosphor Bronze. Employs a flat flexible configuration known as FFC, FPC. Maintains a height of 0.071" (1.80mm) above the board to accommodate assembly and clearance requirements. Constructed from Liquid Crystal Polymer (LCP), Glass Filled, Halogen Free material to guarantee strength and reliability. Classification UL94 V-0 for adherence to fire safety regulations. Mounting configuration Surface Mount, Right Angle for structural stability. Overall number of positions 31 for switches or mechanical components. Temperature range -55°C ~ 105°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Distance 0.020" (0.50mm) for arranging components or aligning connectors. Product status Active concerning availability and lifecycle. Classification series for the product or component SFV-R. Termination method Solder for electrical or mechanical connections. Voltage specification 50V for electronic devices.
