Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | MINIPAK HD | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Plug Application Role | Daughtercard | |
| Interface Connector Category | Plug, Male Blades and Female Sockets | |
| Plug Design Type | MicroTCA™ | |
| Switch Position Options | 96 | |
| Populated Position Count | All | |
| Component Spacing Distance | 0.079" (2.00mm) | |
| Grid Row Count | - | |
| Grid Column Count | - | |
| Attachment Mounting Style | Through Hole | |
| Circuit End Method | Press-Fit | |
| Standard Pin Arrangement | 72 Signal, 24 Power | |
| Key Product Highlights | Mating Guide | |
| Pin Surface Treatment | Gold | |
| Pin Coating Depth | 30.0µin (0.76µm) | |
| Visual Hue | - |
Description
Utilizes a connector style known as MicroTCA™. Features a connector type acknowledged as Plug, Male Blades and Female Sockets. Intended for connector roles classified as Daughtercard. Includes contact finish plated at Gold to improve conductivity. Represents the thickness of the contact finish recorded at 30.0µin (0.76µm). Provides a standard contact configuration characterized as 72 Signal, 24 Power. Equipped with features categorized as Mating Guide. Mounting configuration Through Hole for structural stability. Overall number of positions 96 for switches or mechanical components. Occupied positions All for mechanical assembly. Type of housing Tube for safeguarding or transporting components. Distance 0.079" (2.00mm) for arranging components or aligning connectors. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component MINIPAK HD. Termination method Press-Fit for electrical or mechanical connections.
