Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Plug Design Type | D-Sub | |
| Interface Connector Category | Plug, Male Pins | |
| Switch Position Options | 25 | |
| Grid Row Count | 2 | |
| Attachment Mounting Style | Surface Mount, Right Angle | |
| Connector Shell Configuration | 3 (DB, B) | |
| Pin Interface Category | Signal | |
| Flange Design Element | Housing/Shell (4-40) | |
| Circuit End Method | Solder | |
| Main Construction Material | Metal | |
| Housing Material and Surface | Steel, Nickel Plated | |
| Pin Surface Treatment | - | |
| Pin Coating Depth | - | |
| Dust Water Resistance Rating | - | |
| Fire Resistance Classification | UL94 V-0 | |
| Ampere Capacity Rating | 5A | |
| Rear Connector Gap | - | |
| Key Product Highlights | Board Guide, Grounding Indents |
Description
Utilizes a connector style known as D-Sub. Features a connector type acknowledged as Plug, Male Pins. Makes use of a contact type known as Signal. Sets the ampere rating to 5A. Equipped with features categorized as Board Guide, Grounding Indents. Offers flange specifications defined as Housing/Shell (4-40). Classification UL94 V-0 for adherence to fire safety regulations. Mounting configuration Surface Mount, Right Angle for structural stability. Overall number of positions 25 for switches or mechanical components. Overall rows 2 for setting up matrices or displays. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Primary material Metal for structural and functional applications. Product status Active concerning availability and lifecycle. Material and finish of the shell Steel, Nickel Plated for strength. Shell dimensions for connector setup 3 (DB, B) for proper fitting. Termination method Solder for electrical or mechanical connections.
