Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Dura-Con™ | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Plug Design Type | D-Type, Micro-D | |
| Interface Connector Category | Receptacle, Female Sockets | |
| Switch Position Options | 100 | |
| Grid Row Count | 4 | |
| Attachment Mounting Style | Through Hole, Right Angle | |
| Connector Shell Configuration | 0.050 Pitch x 0.043 Row to Row | |
| Pin Interface Category | Signal | |
| Flange Design Element | Mating Side, Female Screwlock | |
| Circuit End Method | Solder | |
| Main Construction Material | - | |
| Housing Material and Surface | Aluminum Alloy, Yellow Chromate Plated Cadmium | |
| Pin Surface Treatment | Gold | |
| Pin Coating Depth | 50.0µin (1.27µm) | |
| Dust Water Resistance Rating | - | |
| Fire Resistance Classification | UL94 V-0 | |
| Ampere Capacity Rating | 3A | |
| Rear Connector Gap | 0.200" (5.08mm) | |
| Key Product Highlights | Shielded |
Description
Provides a rear space of 0.200" (5.08mm) for proper installation alignment. Utilizes a connector style known as D-Type, Micro-D. Features a connector type acknowledged as Receptacle, Female Sockets. Includes contact finish plated at Gold to improve conductivity. Represents the thickness of the contact finish recorded at 50.0µin (1.27µm). Makes use of a contact type known as Signal. Sets the ampere rating to 3A. Equipped with features categorized as Shielded. Offers flange specifications defined as Mating Side, Female Screwlock. Classification UL94 V-0 for adherence to fire safety regulations. Mounting configuration Through Hole, Right Angle for structural stability. Overall number of positions 100 for switches or mechanical components. Overall rows 4 for setting up matrices or displays. Type of housing Bulk for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component Dura-Con™. Material and finish of the shell Aluminum Alloy, Yellow Chromate Plated Cadmium for strength. Shell dimensions for connector setup 0.050 Pitch x 0.043 Row to Row for proper fitting. Termination method Solder for electrical or mechanical connections.
