Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | - | |
| IC Encapsulation Type | Bag | |
| Availability Status | Active | |
| Interface Connector Category | Plug, Male Pins | |
| Switch Position Options | 8 | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Insert Shell Dimension | M12-8 | |
| Military Shell Standard | - | |
| Attachment Mounting Style | Free Hanging (In-Line) | |
| Installation Mount Type | - | |
| Circuit End Method | Screw | |
| Secure Attachment Method | Threaded | |
| Installation Orientation | A | |
| Main Construction Material | Metal | |
| Connector Housing Alloy | Brass | |
| Connector Shell Coating | Nickel | |
| Engaging Pin Coating | - | |
| Visual Hue | Silver | |
| Dust Water Resistance Rating | IP67 - Dust Tight, Waterproof | |
| Fire Resistance Classification | - | |
| Key Product Highlights | Backshell, Coupling Nut | |
| Electromagnetic Interference Protection | Shielded | |
| Ampere Capacity Rating | 2A | |
| Max Voltage Specification | 30VAC/DC | |
| Entry Port Size | 0.236" ~ 0.315" (6.00mm ~ 8.00mm) | |
| Ambient Temp Range | -40°C ~ 85°C |
Description
Supports a cable opening size of 0.236" ~ 0.315" (6.00mm ~ 8.00mm) for convenient entry. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Offered in a shade referred to as Silver to enhance the system's aesthetics. Features a connector type acknowledged as Plug, Male Pins. Sets the ampere rating to 2A. Utilizes a fastening type recognized as Threaded. Equipped with features categorized as Backshell, Coupling Nut. Rated with IP IP67 - Dust Tight, Waterproof to safeguard against dust and moisture penetration. Mounting configuration Free Hanging (In-Line) for structural stability. Overall number of positions 8 for switches or mechanical components. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Alignment A for proper installation or signal positioning. Type of housing Bag for safeguarding or transporting components. Primary material Metal for structural and functional applications. Product status Active concerning availability and lifecycle. Surface treatment on the shell Nickel for visual appeal and protection. Material makeup of the housing Brass for thermal and mechanical properties. Provide shell dimensions M12-8 to ensure connector compatibility. Shielding Shielded for EMI/RFI protection. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Termination method Screw for electrical or mechanical connections. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Voltage specification 30VAC/DC for electronic devices.
