Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 500 | ₹ 1,305.10000 | ₹ 6,52,550.00 |
| 250 | ₹ 1,370.42000 | ₹ 3,42,605.00 |
| 100 | ₹ 1,461.86000 | ₹ 1,46,186.00 |
| 50 | ₹ 1,535.07000 | ₹ 76,753.50 |
| 25 | ₹ 1,612.02000 | ₹ 40,300.50 |
| 10 | ₹ 1,719.65000 | ₹ 17,196.50 |
| 1 | ₹ 2,023.49000 | ₹ 2,023.49 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | VG 95234, CA-B | |
| IC Encapsulation Type | Bag | |
| Availability Status | Active | |
| Interface Connector Category | Receptacle, Male Pins | |
| Switch Position Options | 3 | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Insert Shell Dimension | 10SL-3 | |
| Military Shell Standard | - | |
| Attachment Mounting Style | Panel Mount | |
| Installation Mount Type | Flange | |
| Circuit End Method | Solder Cup | |
| Secure Attachment Method | Reverse Bayonet Lock | |
| Installation Orientation | N (Normal) | |
| Main Construction Material | Metal | |
| Connector Housing Alloy | Aluminum Alloy | |
| Connector Shell Coating | Olive Drab Cadmium | |
| Engaging Pin Coating | Silver | |
| Visual Hue | Olive Drab | |
| Dust Water Resistance Rating | IP67 - Dust Tight, Waterproof | |
| Fire Resistance Classification | - | |
| Key Product Highlights | - | |
| Electromagnetic Interference Protection | - | |
| Ampere Capacity Rating | 22A | |
| Max Voltage Specification | - | |
| Entry Port Size | - | |
| Ambient Temp Range | -55°C ~ 125°C |
Description
Offered in a shade referred to as Olive Drab to enhance the system's aesthetics. Features a connector type acknowledged as Receptacle, Male Pins. Offers mating contact finish rated at Silver. Sets the ampere rating to 22A. Utilizes a fastening type recognized as Reverse Bayonet Lock. Rated with IP IP67 - Dust Tight, Waterproof to safeguard against dust and moisture penetration. Type of mount Flange for easy installation. Mounting configuration Panel Mount for structural stability. Overall number of positions 3 for switches or mechanical components. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Alignment N (Normal) for proper installation or signal positioning. Type of housing Bag for safeguarding or transporting components. Primary material Metal for structural and functional applications. Product status Active concerning availability and lifecycle. Classification series for the product or component VG 95234, CA-B. Surface treatment on the shell Olive Drab Cadmium for visual appeal and protection. Material makeup of the housing Aluminum Alloy for thermal and mechanical properties. Provide shell dimensions 10SL-3 to ensure connector compatibility. Termination method Solder Cup for electrical or mechanical connections.
