Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Buccaneer® 900 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Interface Connector Category | Plug, Female Sockets | |
| Switch Position Options | 4 (3 Power + PE) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Insert Shell Dimension | - | |
| Military Shell Standard | - | |
| Attachment Mounting Style | Free Hanging (In-Line) | |
| Installation Mount Type | - | |
| Circuit End Method | Screw | |
| Secure Attachment Method | Threaded | |
| Installation Orientation | Keyed | |
| Main Construction Material | Plastic | |
| Connector Housing Alloy | Polyamide (PA), Nylon | |
| Connector Shell Coating | - | |
| Engaging Pin Coating | Nickel | |
| Visual Hue | Black, Blue | |
| Dust Water Resistance Rating | IP68/IP69K - Dust Tight, Water Resistant, Waterproof | |
| Fire Resistance Classification | UL94 V-0 | |
| Key Product Highlights | Backshell, Coupling Nut, UV Resistant | |
| Electromagnetic Interference Protection | Unshielded | |
| Ampere Capacity Rating | 32A | |
| Max Voltage Specification | 600VAC/DC | |
| Entry Port Size | 0.512" ~ 0.591" (13.00mm ~ 15.00mm) | |
| Ambient Temp Range | -40°C ~ 85°C |
Description
Supports a cable opening size of 0.512" ~ 0.591" (13.00mm ~ 15.00mm) for convenient entry. Offered in a shade referred to as Black, Blue to enhance the system's aesthetics. Features a connector type acknowledged as Plug, Female Sockets. Offers mating contact finish rated at Nickel. Sets the ampere rating to 32A. Utilizes a fastening type recognized as Threaded. Equipped with features categorized as Backshell, Coupling Nut, UV Resistant. Rated with IP IP68/IP69K - Dust Tight, Water Resistant, Waterproof to safeguard against dust and moisture penetration. Classification UL94 V-0 for adherence to fire safety regulations. Mounting configuration Free Hanging (In-Line) for structural stability. Overall number of positions 4 (3 Power + PE) for switches or mechanical components. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Alignment Keyed for proper installation or signal positioning. Type of housing Bulk for safeguarding or transporting components. Primary material Plastic for structural and functional applications. Product status Active concerning availability and lifecycle. Classification series for the product or component Buccaneer® 900. Material makeup of the housing Polyamide (PA), Nylon for thermal and mechanical properties. Shielding Unshielded for EMI/RFI protection. Termination method Screw for electrical or mechanical connections. Voltage specification 600VAC/DC for electronic devices.
