Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 100 | ₹ 3,732.81000 | ₹ 3,73,281.00 |
| 50 | ₹ 3,919.68000 | ₹ 1,95,984.00 |
| 25 | ₹ 4,115.97000 | ₹ 1,02,899.25 |
| 10 | ₹ 4,390.73000 | ₹ 43,907.30 |
| 1 | ₹ 5,165.56000 | ₹ 5,165.56 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 62GB | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Interface Connector Category | Receptacle, Female Sockets | |
| Switch Position Options | 12 | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Insert Shell Dimension | 14-12 | |
| Military Shell Standard | - | |
| Attachment Mounting Style | Panel Mount | |
| Installation Mount Type | Flange | |
| Circuit End Method | Solder Cup | |
| Secure Attachment Method | Bayonet Lock | |
| Installation Orientation | N (Normal) | |
| Main Construction Material | Metal | |
| Connector Housing Alloy | Aluminum | |
| Connector Shell Coating | Zinc Cobalt | |
| Engaging Pin Coating | Gold | |
| Visual Hue | Olive Drab | |
| Dust Water Resistance Rating | Environment Sealed | |
| Fire Resistance Classification | - | |
| Key Product Highlights | - | |
| Electromagnetic Interference Protection | Unshielded | |
| Ampere Capacity Rating | 7.5A, 13A | |
| Max Voltage Specification | - | |
| Entry Port Size | - | |
| Ambient Temp Range | -55°C ~ 125°C |
Description
Offered in a shade referred to as Olive Drab to enhance the system's aesthetics. Features a connector type acknowledged as Receptacle, Female Sockets. Offers mating contact finish rated at Gold. Sets the ampere rating to 7.5A, 13A. Utilizes a fastening type recognized as Bayonet Lock. Rated with IP Environment Sealed to safeguard against dust and moisture penetration. Type of mount Flange for easy installation. Mounting configuration Panel Mount for structural stability. Overall number of positions 12 for switches or mechanical components. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Alignment N (Normal) for proper installation or signal positioning. Type of housing Bulk for safeguarding or transporting components. Primary material Metal for structural and functional applications. Product status Active concerning availability and lifecycle. Classification series for the product or component 62GB. Surface treatment on the shell Zinc Cobalt for visual appeal and protection. Material makeup of the housing Aluminum for thermal and mechanical properties. Provide shell dimensions 14-12 to ensure connector compatibility. Shielding Unshielded for EMI/RFI protection. Termination method Solder Cup for electrical or mechanical connections.
