Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | CHAMP .085 | |
| IC Encapsulation Type | Tray | |
| Availability Status | Obsolete | |
| Plug Design Type | Outer Shroud Contacts | |
| Interface Connector Category | Receptacle | |
| Switch Position Options | 24 | |
| Grid Row Count | 2 | |
| Attachment Mounting Style | Panel Mount, Through Hole, Right Angle | |
| Circuit End Method | Solder | |
| Flange Design Element | Board Side (4-40) | |
| Device Type Classification | - | |
| Key Product Highlights | Shielded | |
| Pin Surface Treatment | Gold | |
| Pin Coating Depth | 30.0µin (0.76µm) |
Description
Utilizes a connector style known as Outer Shroud Contacts. Features a connector type acknowledged as Receptacle. Includes contact finish plated at Gold to improve conductivity. Represents the thickness of the contact finish recorded at 30.0µin (0.76µm). Equipped with features categorized as Shielded. Offers flange specifications defined as Board Side (4-40). Mounting configuration Panel Mount, Through Hole, Right Angle for structural stability. Overall number of positions 24 for switches or mechanical components. Overall rows 2 for setting up matrices or displays. Type of housing Tray for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component CHAMP .085. Termination method Solder for electrical or mechanical connections.
