Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Shur-Plug | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| End Terminal Category | Male, Pin (Plug) | |
| Barrel Cylinder Width | 0.156" (3.96mm) | |
| AWG Wire Size | 14-18 AWG | |
| Full Overall Length | 0.710" (18.03mm) | |
| Cylinder Barrel Length | 0.350" (8.89mm) | |
| Protective Insulation Layer | Non-Insulated | |
| Circuit End Method | Crimp | |
| Key Product Highlights | - | |
| Pin Alloy Composition | Brass | |
| Pin Surface Treatment | - | |
| Visual Hue | - |
Description
Constructed from the contact material known as Brass. Lists barrel diameter noted at 0.156" (3.96mm). Insulation with a rating of Non-Insulated for safety and efficiency. The length of the barrel 0.350" (8.89mm) intended for connectors or tools. The complete length 0.710" (18.03mm) for thorough dimensional reference. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component Shur-Plug. Classification of terminal Male, Pin (Plug) for electrical or mechanical connections. Termination method Crimp for electrical or mechanical connections. Size of wire gauge 14-18 AWG according to electrical standards.
