Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Device Type Classification | TxRx Only | |
| Radio Frequency Protocol | General ISM < 1GHz | |
| Communication Standard | - | |
| Signal Modulation Technique | 4FSK, ASK, AFSK, FSK, GFSK, GMSK, MSK, PSK | |
| Oscillation Rate Hz | 27MHz ~ 1.05GHz | |
| Maximum Data Throughput | 125kbps | |
| Output Wattage Rating | 16dBm (Max) | |
| Response Sensitivity Level | -137dBm | |
| Total Memory Bytes | - | |
| Serial Communication Ports | SPI, UART | |
| General Purpose I/O Pins | - | |
| Power Supply Voltage | 1.8V ~ 3.6V | |
| Receive Mode Amps | 6.5mA ~ 11mA | |
| Transmit Mode Amps | 7.5mA ~ 48mA | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 28-VFQFN Exposed Pad | |
| Vendor Package Type | 28-QFN (5x5) |
Description
Operates with the receiving current set to 6.5mA ~ 11mA. Features transmitting current rated at 7.5mA ~ 48mA. Provides a maximum data rate potential of 125kbps. Runs at a frequency of 27MHz ~ 1.05GHz. Communication modulation technique 4FSK, ASK, AFSK, FSK, GFSK, GMSK, MSK, PSK for data transmission. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 28-VFQFN Exposed Pad that offers mechanical and thermal protection. Type of package 28-QFN (5x5) that preserves the integrity of the device. The necessary output power 16dBm (Max) for peak device efficiency. Type or family of RF protocol General ISM < 1GHz for communication standards. Rating for the sensitivity of sensor or input response -137dBm. Ports designated for serial communication interfaces SPI, UART. Supplier package type 28-QFN (5x5) for component selection. Voltage requirement 1.8V ~ 3.6V for electrical specifications. Type classification TxRx Only for specifications. Voltage supply 1.8V ~ 3.6V for device operation.
