Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 515.47000 | ₹ 515.47 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Device Type Classification | TxRx + MCU | |
| Radio Frequency Protocol | 802.15.4 | |
| Communication Standard | 6LoWPAN, Zigbee® | |
| Signal Modulation Technique | O-QPSK | |
| Oscillation Rate Hz | 2.4GHz | |
| Maximum Data Throughput | 250kbps | |
| Output Wattage Rating | 3dBm | |
| Response Sensitivity Level | -101dBm | |
| Total Memory Bytes | 64kB Flash, 2kB EEPROM, 4kB SRAM | |
| Serial Communication Ports | JTAG, SPI, USART | |
| General Purpose I/O Pins | 32 | |
| Power Supply Voltage | 1.8V ~ 3.6V | |
| Receive Mode Amps | 15.5mA | |
| Transmit Mode Amps | 9.5mA ~ 16.5mA | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | - | |
| Component Housing Style | - | |
| Vendor Package Type | - |
Description
Operates with the receiving current set to 15.5mA. Features transmitting current rated at 9.5mA ~ 16.5mA. Provides a maximum data rate potential of 250kbps. Runs at a frequency of 2.4GHz. Provides 32 GPIO pins for flexible input/output interfacing. Total memory size 64kB Flash, 2kB EEPROM, 4kB SRAM for device storage capability. Communication modulation technique O-QPSK for data transmission. Overall I/O 32 for digital links. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tray for safeguarding or transporting components. The necessary output power 3dBm for peak device efficiency. Product status Active concerning availability and lifecycle. Protocol for communication 6LoWPAN, Zigbee® for control or interaction. Type or family of RF protocol 802.15.4 for communication standards. Rating for the sensitivity of sensor or input response -101dBm. Ports designated for serial communication interfaces JTAG, SPI, USART. Voltage requirement 1.8V ~ 3.6V for electrical specifications. Type classification TxRx + MCU for specifications. Voltage supply 1.8V ~ 3.6V for device operation.
