Description

Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Operates with the receiving current set to 84mA ~ 87mA. Features transmitting current rated at 276mA ~ 335mA. Provides a maximum data rate potential of 150Mbps. Runs at a frequency of 2.4GHz. Provides 15 GPIO pins for flexible input/output interfacing. Total memory size 4MB Flash, 384kB RAM, 400kB SRAM for device storage capability. Mounting configuration Surface Mount for structural stability. Overall I/O 15 for digital links. Temperature range -40°C ~ 105°C (TA) for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 28-VFQFN Exposed Pad that offers mechanical and thermal protection. Type of package 28-QFN (4x4) that preserves the integrity of the device. The necessary output power 21dBm for peak device efficiency. Product status Active concerning availability and lifecycle. Protocol for communication 802.11b/g/n, Bluetooth v5.0 for control or interaction. Type or family of RF protocol Bluetooth, WiFi for communication standards. Rating for the sensitivity of sensor or input response -98.4dBm. Ports designated for serial communication interfaces ADC, GPIO, I2C, I2S, PWM, SPI, UART, USB. Classification series for the product or component ESP8685. Supplier package type 28-QFN (4x4) for component selection. Voltage requirement 3V ~ 3.6V for electrical specifications. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Type classification TxRx + MCU for specifications. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Voltage supply 3V ~ 3.6V for device operation.
