Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ZigBit™ | |
| IC Encapsulation Type | Tray | |
| Availability Status | Obsolete | |
| Radio Frequency Protocol | 802.15.4 | |
| Communication Standard | Zigbee® | |
| Signal Modulation Technique | - | |
| Oscillation Rate Hz | 2.4GHz | |
| Transfer Speed Mbps | 2Mbps | |
| Output Wattage Rating | 3.5dBm | |
| Response Sensitivity Level | -97dBm | |
| Serial Communication Ports | ISP, JTAG, SPI, UART, USART | |
| RF Antenna Design | Integrated, Chip | |
| Core Integrated Circuit | - | |
| Total Memory Bytes | 256kB Flash, 8kB EEPROM, 32kB SRAM | |
| Power Supply Voltage | 1.8V ~ 3.6V | |
| Receive Mode Amps | 9.6mA ~ 17mA | |
| Transmit Mode Amps | 9.9mA ~ 16.3mA | |
| Attachment Mounting Style | Surface Mount | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Component Housing Style | Module |
Description
Utilizes a Integrated, Chip antenna style for improved signal capture. Operates with the receiving current set to 9.6mA ~ 17mA. Features transmitting current rated at 9.9mA ~ 16.3mA. Delivers a data transfer rate measured at 2Mbps for rapid operations. Demonstrates a sampling rate capability indicated as 2Mbps. Runs at a frequency of 2.4GHz. Total memory size 256kB Flash, 8kB EEPROM, 32kB SRAM for device storage capability. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case Module that offers mechanical and thermal protection. The necessary output power 3.5dBm for peak device efficiency. Product status Obsolete concerning availability and lifecycle. Protocol for communication Zigbee® for control or interaction. Type or family of RF protocol 802.15.4 for communication standards. Rating for the sensitivity of sensor or input response -97dBm. Ports designated for serial communication interfaces ISP, JTAG, SPI, UART, USART. Classification series for the product or component ZigBit™. Voltage requirement 1.8V ~ 3.6V for electrical specifications. Voltage supply 1.8V ~ 3.6V for device operation.
