Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Radio Frequency Protocol | Bluetooth, WiFi | |
| Frequency Classification | UHF (2GHz ~ 3GHz) | |
| Band Center Frequency | 2.4GHz | |
| Operational Hz Spectrum | 2.4GHz ~ 2.5GHz | |
| RF Antenna Design | Chip | |
| Frequency Band Quantity | 1 | |
| Voltage Standing Wave Ratio | - | |
| Reflection Loss dB | -21dB | |
| Amplification Factor | -3.1dBi | |
| Maximum Power Handling | - | |
| Key Product Highlights | - | |
| Circuit End Method | Solder | |
| Dust Water Resistance Rating | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Upper Height Limit | 0.130" (3.30mm) | |
| Intended Uses | Bluetooth, 802.11a/b/g |
Description
Utilizes a Chip antenna style for improved signal capture. Perfectly designed for situations involving Bluetooth, 802.11a/b/g. Offers a center frequency of 2.4GHz. Maintains a 2.4GHz center frequency for reliable signal performance. Categorized within the UHF (2GHz ~ 3GHz) frequency range to meet industry standards. Offers a 2.4GHz ~ 2.5GHz frequency spectrum for broad-spectrum applications. Delivers -3.1dBi gain to enhance signal amplification effectiveness. Maintains a maximum height of 0.130" (3.30mm) to comply with design standards. Mounting configuration Surface Mount for structural stability. Number of frequency bands 1 for frequency allocation. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Type or family of RF protocol Bluetooth, WiFi for communication standards. Loss of signal return -21dB for quality and reflection evaluations. Termination method Solder for electrical or mechanical connections.
