Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Embedded Antenna | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Radio Frequency Protocol | 802.15.4 | |
| Frequency Classification | UHF (300MHz ~ 1GHz), UHF (2GHz ~ 3GHz) | |
| Band Center Frequency | 868MHz, 2.4GHz | |
| Operational Hz Spectrum | 860MHz ~ 870MHz, 2.4GHz ~ 2.5GHz | |
| RF Antenna Design | Stamped Metal | |
| Frequency Band Quantity | 2 | |
| Voltage Standing Wave Ratio | - | |
| Reflection Loss dB | -6dB | |
| Amplification Factor | - | |
| Maximum Power Handling | - | |
| Key Product Highlights | - | |
| Circuit End Method | Solder | |
| Dust Water Resistance Rating | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Upper Height Limit | 0.197" (5.00mm) | |
| Intended Uses | 6LoWPAN, ZigBee™ |
Description
Utilizes a Stamped Metal antenna style for improved signal capture. Perfectly designed for situations involving 6LoWPAN, ZigBee™. Offers a center frequency of 868MHz, 2.4GHz. Maintains a 868MHz, 2.4GHz center frequency for reliable signal performance. Categorized within the UHF (300MHz ~ 1GHz), UHF (2GHz ~ 3GHz) frequency range to meet industry standards. Offers a 860MHz ~ 870MHz, 2.4GHz ~ 2.5GHz frequency spectrum for broad-spectrum applications. Maintains a maximum height of 0.197" (5.00mm) to comply with design standards. Mounting configuration Surface Mount for structural stability. Number of frequency bands 2 for frequency allocation. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Type or family of RF protocol 802.15.4 for communication standards. Loss of signal return -6dB for quality and reflection evaluations. Classification series for the product or component Embedded Antenna. Termination method Solder for electrical or mechanical connections.
